3624 NF Corporation Filter New

3624 NF Corporation Filter New

$7,000
$7,000 $0
Shipping calculated at checkout.
Request a Quote
Estimated Delivery in
5 - 7
business days (based on availability)

Request a Quote To Get A EDU Discount

Login & Get 2% Back on Purchases
Login or Sign Up for Loyalty

Select option

Additional Features:

  • Cutoff frequency: 0.01 Hz to 159.9 kHz
  • No. of channels: 2
  • Roll off: 24dB/oct
  • Max. output current: ±100 mA
  • Filter mode: LP-MF, LP-PL, HPF, BPF, BEF, THRU (MF: maximum flat, PL: phase linear)
  • Operational modes: SEPARATE (separate CH-A and CH-B), CASCADE (serially connected CH-A and CH-B)
  • Pass band gain: X1, X2, X5 selectable at both input and output
  • Input type: Single-ended or floating, selectable
  • Frequency response in THRU mode: DC to 1 MHz (+0.5, -3 dB) typ
  • Input impedance 1MΩ ± 2%
  • Maximum attenuation: 100 dB or greater (up to 100 kHz) 90 dB or greater (up to 100 kHz); 80 dB or greater (up to 1 MHz)
  • GPIB: Standard
  • Power requirements: AC100, 120, 220 or 240V± 10% (max. 250V), switchable
  • Dimensions (mm): 434(W) X 132.5(H) X 400(D)
  • Weight: Approx. 10.5kg
  • Low distortion about 0.02% and low noise about 100 μVrms
  • Function: THRU (vai only input and output amplifiers), LP-MF (max. flat), LP-PL (phase linear ), HPE, BPF and BEF
  • Mode: SEPARATE (independent operating CH-A and CH-B), CASCADE (cascaded CH-A and CH-B)
View full details
More Details
Specifications
Datasheets

The NF Corporation 3624 Dual Channel Programmable filter has an extremely wide frequency range with cutoff frequency 0.01 Hz to 159.9 kHz for LPF, HPE, BPF and BEF(option).The use of the 3620 series is not limited to electronics; it also covers a wide field of physical experiments, studies on physical properties and other related areas. Its attenuation slope is 24dB/oct, and phase linear response is also available in the LPF mode.

Model No

3624

Condition

New

Manufacturer

NF Corporation

Type

Variable
